2017 Felder AD741 used Jointer/Planer combi machine. #BBM2850
2017 Felder AD741 used Jointer/Planer combi machine. #BBM2850
Location:Ontario, Canada
Description
The 2017 Felder AD741 Spiral Head, Jointer/Planer Combination Machine is a premium, European-engineered workhorse belonging to the Felder Group's acclaimed 700 Series. Renowned for its industrial-grade stability and space-saving design, this machine offers a massive 16-inch (410 mm) working width and seamless, synchronized table changeovers ideal for professional woodworking shops.
Specifications
| Manufacturer | Felder |
| Model | AD741 used Jointer/Planer combi machine. |
| Year | 2017 |
| Condition | Used |
| Stock Number | BBM2850 |
| Jointer Working Width | 16⅛" (410 mm) |
| Planer Working Width | 15⅞" (404 mm) |
| Total Jointer Table Length | 78¾" (2,000 mm) — extendable up to 3,800 mm |
| Planing Thicknessing Height | ⅛" to 9" (3 to 230 mm) |
| Max Depth of Cut | 4 mm (approx. 5/32") |
| Min Workpiece Length | 7½" (190 mm) |
| Feed Speeds | 2-speed synchronized drive at 24 and 47 ft/min (6 and 12 m/min) |
| Dust Extraction Port | 120mm |
| Machine Weight | ~1,100 lbs (500 kg) |
Additional Features
Why Buy This Used 2017 Felder AD741?
⚡ Industrial 16-Inch Capacity, Half the Footprint
Why compromise on shop space or board width? The AD741 packs a massive 16-inch jointing and planing capacity into a single footprint. Flatten wide slabs, gluelines, and rough lumber effortlessly without needing separate, oversized industrial machines.
⏱️ Sub-Minute Changeovers
Forget the tedious breakdowns associated with older combo units. The AD741 features dual, spring-assisted, synchronized cast-iron tables that lift together in one fluid motion. You can switch from precision jointing to thickness planing in under 60 seconds without removing your fence assembly.
🏗️ Uncompromised European Rigidity
Weighing in at over half a ton of heavy-duty cast iron and steel, this machine eliminates vibration entirely. The rock-solid, parallel-guided jointer tables stay co-planar pass after pass, ensuring perfect 90-degree edges on pieces up to 12 feet long when paired with extension tables.
💰 Skip the New Machine Depreciation
A brand-new Felder is an investment that requires long factory wait times and premium freight pricing. Opting for this 2017 model lets you acquire Austrian-built, heirloom-quality machinery that has already leveled out its initial depreciation. It delivers the exact same 1/10th-of-a-millimeter precision as a factory-fresh unit for a fraction of the cost.
