2015 SCM ME35 Used Edgebander #BM2335

2015 SCM ME35 Used Edgebander #BM2335

Uxbridge, Canada

orCall +1 (647) 384-9663

Description

2015 SCM ME35 Used Edgebander


Click INSTANT PRICE anywhere you see it on our site to receive an instant auto-quote, with Pricing and Specs, directly to your email!!


* All Descriptions, Specifications and Features are correct to the best of our knowledge. Interested buyers should verify before purchasing.

Specifications

ManufacturerSCM
ModelME35 Used Edgebander
Year2015
ConditionUsed
Stock NumberBM2335
QualityVery Good
Electrics220V / 1 Ph / 60 Hz

Additional Features

Main Features:
Pre-milling function with 2 diamond cutters allows a very good panel finish and linearity during pre-machining. Removable thickness is 0.5mm to 2mm.
Trimming unit uses the same High frequency motors found in larger SCM edgebanders offer less vibration and more reliability and precision. The radius part of the cutter is used to trim 2mm edges. And chamfered thin edges. The straight part is used for trimming wood edges up to 5mm thickness.
End cutting unit includes radius function. The flat part of the blade will cut thin tape while the curved part will perform the radius function.
Glue scraping unit: eliminates any excess of glue in the joint between the panel and the edge, improving the panel cleaning.
Brushing unit: 2 independent motors to perform the cleaning and polishing action.
Multiple high-frequency motors used throughout this edgebander to reduce vibration and provide the highest quality finish at all times.
Automatic lowering of the glue pot temperature after a temporary non-use of the machine.
Automatic edge loading system for rolled edges with shear device for 3mm max. thickness edges and 50mm height
7 meters/min feed speed
Electrical requirements: 230v, single phase, 34 amps
Machine weight: 1347 lbs
Required footprint: 57ÔÇŁ x 131ÔÇŁ
Made in Italy
Technical Specifications:
Worktable dimensions: 3000mm x 525mm
Worktable height: 904mm
Thickness of rolled edges: 0,4mm / 3mm
Thickness of edges in strips: up to 5mm
Min. / max. panel height: 8mm / 50mm
Min. panel length/width with rolled edges: 190mm/110mm
Min. panel length cut only on the front: 120mm
Feed speed: 7m / min
Feed motor power S1: 0.55 kW
Pneumatic operating pressure: 6.5 bar
Exhaust outlet diameter (glue pot): 60mm
No. 2 exhaust outlets diameter (trimming unit): 60mm
No. 2 exhaust outlets diameter (pre-milling unit): 80mm
Operating temperature: 20 / 190 ┬░C
