Laguna DT-18 Dovetail Machine
Laguna DT-18 Dovetail Machine
Location:Ontario, Canada
Description
Laguna DT-18 Dovetail Machine
Click INSTANT PRICE anywhere you see it on our site to receive an instant auto-quote, with Pricing and Specs, directly to your email!!
* All Descriptions, Specifications and Features are correct to the best of our knowledge. Interested buyers should verify before purchasing.
Specifications
| Manufacturer | Laguna |
| Model | DT-18 Dovetail Machine |
| Condition | Used |
| Stock Number | BBM2196 |
| Quality | Very Good |
| Electrics | 220 V / 3 Ph / 60 Hz |
| Weight | 1320 lbs |
Additional Features
Maximum Work-Piece: 59″ x 16″
Pneumatic Clamps: 4 With Individual Controls
Spindle Speed: 21,500 RPM
Motor: 2HP
Base Size: 42″ x 22″
Machine Size: 56″ x 36″
Dust Port: 4″
Air Pressure Requirement: 71 psi
Weight: 1,320 lbs
Shipping Dimensions (L x W x H): 60″ x 50″ x 50″
Thickness of Tenon: ⅛″ – 2-23/64″
Width of Tenon: 15/64″ – 23/32″
Depth of Tenon: 25/64″ – 1-3/16″
Cutter Bit Vertical Adj. 1-3/16″
